High End 8mm Glass Lens 635nm 1mW 5mW Red Dot Laser Module Industrial Grade APC Driver

Optical and Electrical Characteristics (TC = 25°C, unless otherwise specified) Control Method: CW Wavelength：635nm Lens：Glass Spot: Dot Spot Size: <6*8mm at 10m Dimensions：8*20mm Output power：1mW Operating Voltage: 3V/5V DC Operation current: 10~42mA, 50mA MAX. Power Stability: <5% Divergence Angle: <0.7 Operating Temperature: -10℃~ +50℃ Storage Temperature: -40℃~ + 85℃ Housing Material: Brass/Aluminum Operation Mode: APC(Auto Power Control) Mean time to failure: >8,000 hrs Applications -- Industrial areas -- Medical -- Biochemical -- Laser Tag Customized Lasers In the event that none of our standard products meet your exact requirements, our customized design service provides single prototypes and small production runs in just a few days. Our engineering and Design Team have over 10 years in low power laser diode module design. About Us MXTLASER is a company focused on semiconductor laser product development and production enterprises, the company since its inception has been committed to professional semiconductor laser products for the direction; always adhere to carry forward the 'integrity, innovation, communication' for business purposes, 'technology, services' as the core competitiveness of the company Products are mainly used in medical, biological engineering, industrial equipment, 3D printing set.

• Diameter: 8mm / Visible light: ʎ = 635nm (Low power consumption)
• Glass lens: Produces an elliptical collimated beam or focal spot. / APC(Auto Power Control): automatically adjust the input current in order to output a constant value of optical power.
• Aluminum structure for the best shock resistance and better heat transfer consideration.
• We have standard size of 4mm, 6mm, 8mm, 9mm, 10mm, 12mm, 18mm and 20mm. Also please feel free to contact us to customize as your requirements.
